400W BSW Moving Head Stage Lights

VT-400BSW The 400W OSRAM Bulb Moving Head Light is a top - tier lighting fixture, designed to elevate your lighting experiences. Powered by a 400W OSRAM bulb, it delivers intense and brilliant illumination. OSRAM, a renowned name in lighting technology, ensures consistent high - quality light output, with a color temperature that provides a natural and vivid glow.​
This moving head light offers an array of stunning lighting effects. Its optical system is optimized to create sharp and well - defined beams, perfect for highlighting specific areas or performers. The color - creating capabilities are remarkable. It comes with a color wheel featuring multiple vibrant colors.
The moving head design provides exceptional flexibility. With a wide pan and tilt range, it can precisely target various areas of a stage or venue. The high - precision movement mechanism, often with 16 - bit control, guarantees smooth and accurate positioning. This enables lighting designers to craft dynamic and professional lighting shows, whether it's for a high - energy concert or an elegant theater performance.​
In terms of control, it supports the industry - standard DMX512 protocol, making it easy to integrate into existing lighting control systems. Additionally, it may offer other control options such as master - slave operation and sound - activated modes, adding versatility for different event setups.

EMAIL


OVERVIEW



·OSRAM SIRIUS HRI 371


· Zoom range: 2.5~60° , 2.5-8°(beam), 22-55° (wash) ,5-55°(spot)


·0%-100% linear focus


·7-colors mirror to achieve colorful effects

· Efffect: Prism, Static gobo wheel, Rotating gobo wheel, animation wheel, colour wheel


· Usage: Theatre & opera, concert, stadium & sport venues,television, events & trade shows, permanent Installations



SPECIFICATIONS



SOURCE:

Light source: OSRAM SIRIUS HRI 371

Color Temperature: 7500K



CONNECTIONS:

DMX in/out : 3-pin XLR

Power : PowerCon



POWER SYSTEM:

Voltage : AC100-240V 50/60Hz

Power consumption: 650W



Cooling system

Copper tube+Fan cooling system

OPTICS:

Zoom range : 2.5~60° , 2.5-8°(beam), 22-55° (wash) ,5-55°(spot)

Focus: 0%-100% linear focus

High-density glass optical lens




Work Environment:

Maximum ambient temperature: 40°C

Minimum operating temperature: -10°C

Maximum surface temperature: 65°C



COLOR:

Color wheel: 11 colors+open

Colorful mirror: 7-colors mirror to achieve colorful effects







IP Rating:

IP20



GOBO:

Rotating: 7 interchangeable glass gobos +open

Static gobo: 13 gobos+open

Animation: 1 wheel







SIZE/WEIGHT:

Fixture size:

Carton size:

Net weight:

Gross weight:




EFFECTS:

Prism: 8+16 linear prisms, motorized, rotating

Dimmer: 0%-100% Linear dimming

Strobe: 1-25times/sec High Speed Electronic Strobe





WARRANTY:

2 Years



MOVEMENT:

Pan:0-540°(16-bit control)

Tilt: 0-270°(16-bit control)

Automatic Pan/Tilt position correction



APPROVALS:

CE & RoHS

CONTROL:

Control Protocols: DMX512

Remote control on/off lamp function, self mode, master-slave mode, sound mode

2 DMX Channel Modes (18/22CH)

LCD display
